E5620/2GB DDR3 1333 REG ECC/No HDD/ASMB4-iKVM 1U內含2台

型號：RS700D-E6-E5620-PS8

送出詢價不代表訂單成立。我們將依商品、數量與需求，確認價格及供貨狀況後回覆。

其他聯絡方式

電話：02 2761-1882

Email：info@fest.com.tw

LINE 官方帳號：［待確認］

規格

Anti-virus Software	不含防毒軟體
EMI	US (FCC, CFR47 Part 15, Class A, Class B)、Europe (CE, EN55022 & EN55024)、Australia (C-TICK)、Taiwan (BSMI)、China (CCC)
Environment	Operation temperature: 10℃ ~ 35℃ / Non operation temperature: -40℃ ~ 70℃；Non operation humidity: 20% ~ 90% ( Non condensing)；Non operation humidity: 20% ~ 90% (Non condensing)
Expansion Slots	Total Slots: 1 per Node；Slot Type: 1 * PCI-E 2.0 x16 slot (x16 link)(Low profile/Half-Length) per Node
HDD 擴充槽	4 x Hot-swap 2.5
Management Solution	Software: ASWM2.0；Out of Band Remote Management: Optional ASMB4-iKVM for KVM-over-IP support
OS Support	RedHat® Enterprise Linux AS5.0 (32/64 bit)、SuSE® Linux Enterprise Server 10 (32/64 bit)、Windows® Server 2003 Enterprise R2 SP2 32/64-bit、Windows® Server 2008 Enterprise 32/64-bit (Subject to change without any notice)
Safety	Europe (CE, EN55022 compliance to EU Directive 89 / 366/ EEC)、Europe (TUV)
SATA介面	SATA Controller Intel® ICH10R: 6 SATA2 300MB/s ports；Intel Matrix Storage (for Windows only) (Support software RAID 0, 1)；LSI® MegaRAID (for Linux/Windows) (Support software RAID 0, 1)
主機尺寸	686 mm (H) x 444 mm (W) x 43.4 mm(D)
主機外觀	機架式設計
光碟機	無光碟機
其它	ASMB4-iKVM；提供台灣本島西半部都會區333全免,當日四小時到場保固(3年5*8)(可選購保固升級套件)
重量	18 Kg (不包含CPU、記憶體及硬碟)
記憶體 (Std/Max)	2GB DDR3 1333 REG ECC
記憶體(DIMM 數)	Total Slots: 12 DIMMs per Node (3-channel per CPU, 6-DIMM per CPU)；Capacity: Maximum up to 96GB (RDIMM) per Node; Maximum up to 24GB (UDIMM) per Node；Memory Type: DDR3 1066/1333 Reg DIMM/ Unbuffered DIMM with ECC；Memory Size: 1GB 2GB 4GB 8GB * (RDIMM); 1GB 2GB (UDIMM)
最大支援處理器數量CPU	1U 雙節點雙CPU平台
傳輸介面	1 x Internal A Type USB Port per Node、1 x External Serial Port、3 x RJ-45 ports (One for ASMB4-iKVM)、3 x USB2.0 ports (Front * 1, Rear * 2) 、1 x VGA port
電源控制器	1 (80+) Cold-Swap Power Supply per Node
磁碟控制介面	內建 SATA SW RAID 0,1,1E
網路介面	LAN: 2 * Intel 82574L + 1 * Mgmt LAN per Node
標配處理器CPU(規格/數量)	Intel Xeon E5620 2.40GHz；晶片組:Intel® 5500 IOH、Intel® ICH10R I/O Controller；2 x Socket 1366
熱抽硬碟	每一節點可支援四顆熱抽取2.5吋硬碟
顯示卡	VGA: Aspeed AST2050 8MB
